Explore the 42" infrared touch all-in-one computer, supporting Intel i3/i5/i7 processors, suitable for high-end office and home entertainment. Excellent performance and large screen display bring extraordinary experience.42 inches
Specification：
Model No：DL-AIO42
Panel size：42″ TFT-LCD
Panel brand：Sangsung or LG
Input Frequency：Horizontal:30-80KHZ,Vertical:60-75HZ
Display area(mm)/mode：16:9
Maximum resolution：1920x1080P
Display color：16.7M
Pixel Pitch(mm)：0.264mmx0.264mm
Brightness (nits)：500cd/m^2
Contrast：1000:1
Visual angle ：65(L)/65(R)50(U)/50(D)
CPU Master Frequency：intel i3(2320 2.6GHz)/ i5 i7option
chipset of MB：intel H61
Memory：4GB DDR3
Storage：1TB HDD (barebone accept)
Operating Sysem：linux/ubuntu/win7/winXP
graphics card video memory：integrated Intel HD chipset
heatsink cooling：80*2dual ball bearing
touch screen input：IR multi-touch screen
Response time：8ms
Life(hrs)：>50,000(hrs)
Input and output：
RF：1
HDMI INPUT：2
S-VIDEO INPUT：1
USB：6 USB2.0 port(support 480Mb/s transfer rate)
VGA：1
AV INPUT：2
YPbPr：2
PC Audio INPUT：1
Explansion slots：PCI-E *2
SD/MMC/MS：0
RG45(LAN)：1
onboard SATA ：2 SATA port
Video port ：HDMI + DVI/VGA
onboard Audio ：6.1 chanel Support MIC-in,Line-out,Line-in
Wifi：1
Speaker：2×3W(4Ω)
Video：
Color system：PAL/SECAM
Sound System：BG/DK/I/L,L' ,NICAM/A2
Max. Channel Quantity：99CH
Remote controller：IR Remote Controller
OSD display( screen menu display)：Menu language：Chinese/English( Multiple Language Supported)
Power：
Power supply：AC100~240V 50 /60 HZ
Maximum power consumption：<=170W
Standby power consumption：<5W
Temperature：
Working temperature:0ºC~50ºC
Storage temperature:-20ºC~60ºC
Working humidity:85%
Storage humidity:85%
Appearance：
Color/appearance:White,black,customized
Case:Plastic shell
Installation:Stand/Wall mount
Quality Standard:ISO9001,CCC
Detailed functions：
Built-in Analog Tuner:ATSC
Video format:MPEG1/MPEG2/MPEG4/DivX/ASP/WMV/AVI
Audio format:Wave/MP3/WMA/AAC
Image format:JPEG/BMP/TIFF/PNG/GIF
Image resolution:480P/720P/1080P
Optional Functions:(Be free to contact sales man to confirm the Extra cost for optional)
Digital TV System:DVB-T/ISDB-T ATSC
Bluetooth:Y
Tempered glass:7 degree Glasses
Outdoor Waterproof :IP65/68
Light adjusting :Levels according to the unit
FAQ
1.How many years warranty do you offer for Products?
We offer 1 year warranty.
2. What included in products?
It is included Product, Power and user manual.
3. Minimum order quantity?
We can offer your required quantity as we don't dictate MOQ terms.
4. How do I pay?
You can pay us by T/T, Western Union, Paypal or other way.
It can be negotiable.
5. Is your Price Negotiable?
Yes, we are Customer Oriented Company and we believe in supporting
Customer at their best requirement.
6. How does your factory do regarding quality control?
Quality is priority. Hopestar always attach great importance to quality controlling from the every beginning to the every end.
